產(chǎn)品中心
| 型號(hào) | 最大像面 | 分辨率 | 焦距 | 光圈 | 視場(chǎng)角 | TV畸變 | 最近距離 | ||
| 1" | 2.3" | 1/2" | |||||||
| XM1205A | 1" | 5M | 12.5mm | 1.4~16 | 54.5°x42° | 38.5°x29.1° | 28.8°x21.7° | <1.8% | 0.1m、0.0106X |
| XM1605A | 1" | 5M | 16mm | 1.4~16 | 42.4°x32.4° | 29.9°x22.7° | 21.2°x16.5° | <0.2% | 0.1m、0.146X |
| XM2505A | 1" | 5M | 25mm | 1.4~16 | 28.7°x22.06° | 20.34°x15.78° | 15.34°x11.84° | <0.1% | 0.1m、0.27X |
| XM3505A | 1" | 5M | 35mm | 1.4~16 | 19.28°x14.32° | 13.14°x9.8° | 9.58°x7.16° | <0.1% | 0.15m、0.244X |
| XM5005A | 1" | 5M | 50mm | 1.6~16 | 13.86°x10.4° | 9.56°x7.16° | 6.96°x5.3° | <0.1% | 0.3m、0.163X |
| XM7505A | 1" | 5M | 75mm | 1.8~16 | 9.8°x7.4° | 6.74°x5° | 4.9°x3.6° | <0.1% | 0.8m、0.115X |
